Viair 95c Black Light Duty Air Compressor

Newmatics Inc.1832 Lone Star Rd, Mansfield, TX 76063


  We offer combined shipping on all orders

Parts Sold For OFF Road / Show USE Only

PLEASE READ THE ENTIRE LISTING AND SHIPPING TERMS BEFORE BUYING

SAME DAY FREE & FAST SHIPPING

Add Stealth Black Air Compressor for show class look for your next Air Ride Setup Motor Cycle or any small air needs

VIAIR's 95C Series compressors offer a light duty solution for smaller air requirements and are meant to fill no larger than a 1.0 gallon air tank. Multiple duty cycle, mounting, compressor finish and intake options are available depending on model. This 95C Stealth Black Air Compressor comes with Omega Style Mounts (Mounting Brackets) with Nuts & Bolts.

Please Note: Use thread sealant for proper installation. Thread tape is not recommended.
Properly sealed, recommended torque for 1/8” is 10 ~ 11 ft. lbs. Recommended torque for 1/4” and 3/8” is 16 ~ 18 ft. lbs.

***Use 40 AMP 4 Pin Relay OR higher amps Relay with pressure switch to turn ON and OFF this compressor automatically. Do not wire this compressor direct with pressure switch only. Pressure switch may burn due to spike in AMPS.***

NOTE : Do not use a higher psi pressure switch with this compressor. Higher than 130 PSI max pressure switch will Void manufacturer warranty. Use Non- Permanent threads sealant to screw fitting into inbuilt check valve at front on this compressor. Do not over tighten fitting in to check valve, excessive over tightening may crack this check valve. Use recommended torque specified by manufacturer (Viair). Max Air Tank Size 1.0 Gallon

Included Parts:
- Check Valve
- Omega Brackets
- Vibration Isolators
- Mounting Hardware
- Installation Instructions

Specifications:

- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 10% @ 100 PSI
- Max. Working Pressure: 120 PSI
- Max. Air Tank Size: 1.0 Gallon
- Max. Amp Draw: 10 Amps
- Ingress Protection Rating: IP54
- Dimensions: 5.4"L x 3.1"W x 4.5"H

Fill Rates:

0.5 Gallon Tank

Fill Rate

0 to 105 PSI

1 min 05 sec. (± 05 sec.)

85 to 105 PSI

15 sec. (± 03 sec.)

0 to 120 PSI

1 min. 20 sec. (± 05 sec.)

90 to 120 PSI

25 sec. (± 03 sec.)

1.0 Gallon Tank

Fill Rate

0 to 105 PSI

2 min. 10 sec. (± 10 sec.)

85 to 105 PSI

31 sec. (± 05 sec.)

0 to 120 PSI

2 min. 40 sec. (± 10 sec.)

90 to 120 PSI

50 sec. (± 05 sec.)
