Viair 350c Air Compressor

Newmatics Inc.1832 Lone Star Rd, Mansfield, TX 76063


  We offer combined shipping on all orders

Parts Sold For OFF Road / Show USE Only

PLEASE READ THE ENTIRE LISTING AND SHIPPING TERMS BEFORE BUYING

Brand New UN-used Viair 350C Air Compressor Piston & Connecting Rod with counter weight, Viair 350C Cylinder wall with two O'Rings (Gaskets) & Viair 350C Head Rebuild kit with 4 bolts.

Make Sure you have Viair Brand 350C Air Compressor. This kit will work for Viair 35030 and 35033 part number air compressors.

***Piston Ring does not come by itself *** Comes as complete assembly only***

TIP: All Viair air compressors come with 5 digit part number stamped at top front side of crank case. Just remove the direct air inlet filter housing to see compressor part number. 350C will have these two part numbers stamped on crank case - 35030 & 35033.

4 digit numbers are located right below this 5 digit compressor part number. First 2 are year and next 2 are month of manufacturing. This will help you to determine age (how old) is your compressor

NOTE: Replacement head will not come with upper reed valve plate. Use your old reed valve plate in this new head. Clean old reed valve plate to remove carbon or dust  build up.

***This reed valve plate must be installed with correct orientation & direction. Mark reed valve plate orientation and direction in old head before taking it out.***

Parts include:

- 350C Connecting Rod & Piston Rebuild Kit With Counter Weight & Set Screw

- 350C Cylinder Wall Rebuild Kit With upper and lower gaskets

- 350C Head Replacement Rebuild Kit with 4 bolts.

*** Apply Non-permanent thread sealant to set screw, to make sure piston does not move on motor shaft. Do not over tighten head bolts, these may shear due to excessive tightening***
