Square Air Cooled Spindle Motor 2.2KW CNC Spindle Motor 220V ER20

• Technical Parameters: Spec: φ2.4 x 10.3 in (Diameter: 6.2 cm x Length: 26.1 cm); Power: 2.2KW; Voltage: 220V; Current: 7.8A; Collet Size: ER20; Bearings: 4 bearings; Frequency: 400 Hz; Speed: 24000 R/min; Runout off: less than 0.01 mm. Mainly used for engraving machine or used with frequency converter.
• ER20 Standard Collet: The collet of the CNC router spindle is quenched with manganese steel, and the runout is less than 0.01 mm, which has high precision and is not easy to break the knife, increasing the stability of the working process. Dynamic balance technology can effectively reduce noise during use.
• Powerful Bearing: The air spindle motor adopts imported bearings with high accuracy, precision, and durability. Significantly improve the hardness and anti-rust performance.
• Low Noise & Heat Dissipation: The dynamic balance technology can effectively reduce the noise during use. The scientifically designed air cooling system has a better heat dissipation effect to ensure smooth operation.
• Wide Application: The CNC spindle motor kit is mainly used for engraving machines or frequency converters. It uses air circulation to cool the heat and has a good heat dissipation effect.

Key Features

• Dynamic Balance Technology

  Unlike other milling spindle motors, we use innovative and advanced dynamic balancing technology. The ER20 standard collet's advantages are excellent rigidity, full strength, unique drainage design, and high precision.

• Four High-quality Bearings

  The upgraded bearing has two significant advantages: superior durability and anti-rust performance. High speed (24000R/min) and strong power bring higher efficiency than before.

• Noise Reduction and Air Cooling

  Our CNC router spindle motor works with low noise and avoids auditory fatigue. It uses air circulation to cool the heat generated by the spindle at high speed and has a good heat dissipation effect.

• Premium Material

  The aluminum body ensures greater power and longer life; Unlike ordinary aluminum-clad wire, the oxygen-free copper coils can ensure high-quality processing and engraving performance.

• Refined Internal Details

  The CNC router spindle is a built-in wire box directly connected to the wire or VFD, effectively improving the stable and smooth operation. The upgraded wrench is provided for easy handling.

• Wide Application

  Air-cooled motors commonly applied materials such as wood, stone, mold & metal, etc. Suitable for machinery manufacturing, sheet metal processing, guardrails, factories, shipyards, home improvement, construction, and other fields.

2.2KW Air Cooled Spindle Motor

These spindle motors adopt imported bearings and high-quality materials, and their service life is three times that of ordinary spindle motors. Widely applicable to engraving machines for wood, stone, metal, and other materials.

• Technical Parameters
• ER20 Standard Collet
• Powerful Bearing
• Low Noise & Heat Dissipation

Specifications

• Power: 2.2 KW
• Voltage: 220V
• Frequency: 400 Hz
• Speed: 24000 R/min
• Runout off: Less than 0.01 mm
• Collet Size (Dia.): 0.005" / 0.02" / 0.24" (0.125 mm / 0.5 mm / 6 mm)
• Connection of Spindle End: ER20 ø 0.125"-0.5" (3.175 mm-12.7 mm)
• Bearing Model: 7005 x 2, 7002 x 2
• Maximum Torque: 1.2NM
• Product Dimension: 2.4 x 10.3 in / 6.2 x 26.1 cm
• Weight: 13.2 lbs / 6 kg

Package Content

• 1 x Air Cooled Spindle Motor
• 2 x ER20 Collets
• 2 x Wrenches
