New 13.5 Cfm 1 Hp Oilless Pond Aerator Vacuum Pump Rotary Vane Compressor

GAST / EasyPro High Quality Rotary Vane Aeration Compressors offer continuous duty aeration for Numerous applications including vacuum forms, presses, chucking, compressor applications such as aerating large ponds, small lakes, etc. Ideal for both summer time aeration and winter time de-icing. Medium pressure, oil free compressors are excellent for pond and lake aeration and de-icing. These do a great job of aerating all year long. Long lasting, continuous duty compressors offer less depth capabilities than the diaphragm or rocking piston compressors but produce considerably more air

Several advantages including:

• Very Reliable
• Oil-less Operation
• 18' maximum operating depth
• Easily Replaceable vanes
• UL listed - for outdoor use
• Made in the USA

Specifications:        (  ALSO Available in 220V )

• RV100 Rotary Vane Air Compressor 1 HP Single Phase
• Amps: 14 @ 115volts - Max PSI: 10 - All models have an 18 ft maximum operating depth, they come with air filter and 6 ft power cord
• CFM Air Flow 13.5 @ 0 Feet of Water Depth / 11.7 @ 12 Feet
• Medium pressure, oil-free compressors are excellent for pond and lake aeration and de-icing
• Long lasting, continuous duty compressors offer less depth capabilities than the diaphragm or rocking piston compressors but produce considerably more air
• 1 Year Limited warranty on compressor

Aerates ponds up to:

• 1/2 acre pond - 5' to 8' deep
• 1 acre pond - 8' to 12' deep
• 2 acre pond - 12' to 18' deep

Air Flow Chart:

CFM Air Flow @ Water Depth of Feet:Part #HorsePowerAmps/Volts0'6'12'18'RV1001 HP14/115v13.512.411.710.4
Technical Specs

• ItemCompressor/Vacuum Pump

• Output Power1 hp

• PhaseSingle

• Voltage115/230V AC

• Inlet Size3/8 in

• Inlet TypeNPT

• Outlet Size3/8 in

• Outlet TypeNPT

• Free Air Flow Rate13.2 cfm

• Maximum Vacuum26 in Hg

• Maximum Continuous Pressure10 psi

• Maximum Speed1, 725 RPM

• Maximum Intermittent Pressure10 psi

• EnvironmentPond Aeration

• Fluid CompatibilityAir

• Current Rating13.0/6.5 A

• Frequency50/60 Hz

• Power SourceCorded Electric

• Duty CycleContinuous

• Housing MaterialCast Iron

• Bearing TypePermanently Lubricated Sealed Bearings

• Overall Length16.95 in

• Overall Width6.5 in

• Overall Height8.8 in

• IncludesFilter, Integral Muffler

• StandardsCSA Approved
