HIGH FLOW INDUSTRIAL GRADE FILTER REGULATOR COMBO FOR COMPRESSED AIR,

SUPER HEAVY DUTY INDUSTRIAL GRADE PIGGY BACK / INTEGRAL STYLE FILTER REGULATOR COMBINATION

PUSH PULL ADJUSTMENT KNOB THAT SHOWS PRESSURE INCREASE AND DECREASE MARKED ON TOP OF THE KNOB.SIMPLY LIFT KNOB TO ADJUST PRESSURE RANGE AND PUSH DOWN TO LOCK INTO PLACE.

180 CFM FLOW RATE

REGULATOR WILL ADJUST 7 PSI MINIMUM THROUGH 175 PSI MAXIMUM
175 PSI MAXIMUM INPUT PRESSURE

1" FEMALE NPT INLET  X  1"  FEMALE NPT OUTLET.
PLEASE NOTE IF DETERMINING YOUR NPT THREAD SIZE WITH A TAPE MEASURE, RULER OR CALIPER.  1" NPT MEASURES 1.315" OUTSIDE THREAD DIAMETER IN INCHES.

11oz   METAL BOWL WITH VISIBLE SIGHT GLASS TO VIEW MOISTURE LEVELS AT A GLANCE.

INCLUDES INTERNAL FLOAT DRAIN ( AUTO DRAIN). AUTO DRAIN HAS 1/8" MALE NPT CONNECTION.

WALL MOUNTING BRACKET AND BACK MOUNT PRESSURE GAUGE INCLUDED WITH EACH UNIT. GAUGE PORT IS 1/4" FEMALE NPT.

OPERATION INSTRUCTIONS ALSO INCLUDED.

5 MICRON ELEMENT FOR PARTICULATE FILTER REMOVES 95% OF WATER MOISTURE FROM COMPRESSED AIR LINES.

PLEASE NOTE:  THE BEST STAGE 1 MOISTURE PREVENTION IS YOUR COMPRESSED AIR LINES THEMSELVES. ALWAYS FORCE COMPRESSED AIR TO CLIMB VERTICALLY, WHILE WATER AND MOISTURE ARE FORCED DOWNWARDS BY GRAVITY. THIS WILL EXTEND THE LIFE OF YOUR FILTRATION ELEMENTS AND YOUR AIR TOOLS. PLEASE SEE A FEW ATTACHED PICS OF POPULAR COMPRESSED AIR PIPING TECHNIQUES AND INSTALLS.

FOR A TAMPER FREE SAFETY FEATURE, SIMPLY REMOVE THE REGULATOR KNOB ONCE YOU HAVE PRESET TO YOUR DESIRED CUT-IN AND CUT-OUT PRESSURE. THE REGULATOR KNOB CAN ACT LIKE A KEY WHEN YOU NEED TO ADJUST THE PRESSURE AGAIN. THIS PREVENTS PEOPLE FROM TAMPERING WITH THE SET PRESSURE.
