Evolution R355CPS: Multi-Material Cutting Chop Saw With 14 in. Blade

Specifications Cutting Capacities Max. Rectangle Tube (0° x 0°) 3-3/4" x 7-1/8" Max. Rectangle Tube (0° x 45°) 3-1/8" x 4-3/8" Max. Square Tube Cut (0° x 0°) 4-3/4" x 4-3/4" Max. Square Tube Cut (0° x 45°) 3-1/2" x 3-1/2" Max. Round Tube Cut (0° x 0°) 5-1/8" Ø Max. Round Tube Cut (0° x 45°) 4-1/8" Ø Mild Steel Plate - Max. Thickness 1/4" Mild Steel Box Section - Max. Wall Thickness 1/8" Minimum Cut Off Piece Length 5/16"   Blade Spec Blade Dia.: 14 in. No. of Teeth: 36 Bore: 1 in. Kerf: .086 in   Machine Spec Motor (120V 60Hz): 15A Speed No Load: 1450rpm Max. Miter: 45° Packaging Dimensions: 18-1/2 x 22-5/8 x 14-3/4 Inch Product Dimensions: 16-1/8 x 20-7/8 x 12-1/4 Inch Product Weight: 47.4 lbs Packaged Weight: 52.4 lbs



Items Included 14" Multi-Material Cutting TCT Blade (Fitted) Instruction Manual 5/16" (8mm) (Blade Change) Allen Key V-Block



Cutting Applications Wood Hardwood & tanalized decking, MDF laminates, moldings, reclaimed wood with nails, scaffold boards & poles, stud-work.  Ferrous Metal Mild Steel, angled, box section, square tube, metal stud dry walling, rebar, RSJs, plate (1/4 inch), unistrut.  Non-Ferrous Metal Aluminum, armored cables, cable tray, copper, floor edgings, roof flashings, stair nosings.  Plastic Electrical conduit, plastic pipes, plexiglas, rubber & reinforced hoses, (WPC) Wood Plastic Composites.  Not Recommended Hardened high carbon, coated and stainless steel.
Note: Cutting galvanized steel may reduce blade life.
