Click on Thumbnails to Enlarge

CHAMPION/SPEEDAIRE

5–7.5 HP TWO STAGE

SPLASH LUBRICATED COMPRESSOR

CAP# RV15A

Designed for heavy-duty industrial applications. Cast iron cylinders with cooling fins. Pumps are splash lubricated. Balanced, fan-type flywheels provide air flow for cooling pump. Rotation CCW facing flywheel. Intercoolers efficiently dissipate heat.

Pump Design
Large Diameter Intercooler Finned Tubes – Max efficiency
High Flow Disc & Spring Valves – Low lift long life
Tapered Roller Type Main Bearing – Longest Life
Automotive Type Inlet Filter – Easy to check oil level
Oil Sight Glass – Easy to Check Oil Level
Pressure Relief Valves – Intercooler & Discharge

Specifications

HP RANGE 5 – 7.5

MAX PSIG 175
CFM RANGE 9.7 – 23.4

STAGES 2
C.F.DISP PER REV .02916
RPM RANGE 440-990
BORE L.P IN 4-5/8
BORE H.P IN 2-1/2
STROKE IN 3
CYLINDERS 2
LUBRICATION SPLASH
OIL CAPACITY QT 2
DISCHARGE OPENING 3/4″ TUBING
FLYWHEEL DIA IN 16.5
BOLTDOWN WIDTH IN 8-3/4
BOLTDOWN DEPTH IN 5-3/4
HEIGHT IN 24
DEPTH IN 20
WIDTH IN 17
WEIGHT LB 125
