1/4" Mini Regulator With Gauge For Compressor

NEW 1/4" MINI REGULATOR FOR COMPRESSED AIR SYSTEMS AND AIR COMPRESSORS

PLEASE NOTE IF DETERMINING YOUR PIPE SIZE WITH TAPE MEASURE.  1/4" FEMALE NPT MEASURES 0.505" OUTSIDE THREAD DIAMETER IN INCHES

ADJUSTABLE PRESSURE RANGE BETWEEN 7 PSI MINIMUM UP TO 140 PSI MAX OUTPUT PRESSURE

150 PSI IS THE MAXIMUM INPUT PRESSURE TO THIS REGULATOR.

1/4" FEMALE NPT INLET  X  1/4" FEMALE NPT OUTLET

WALL MOUNTING BRACKET INCLUDED

BACK MOUNT 0-160 PRESSURE GAUGE INCLUDED

THIS IS A ONE WAY DIRECTIONAL FLOW REGULATOR WITH THE INLET CLEARLY MARKED BY DIRECTIONAL ARROW.

THIS UNIT CAN BE INSTALLED KNOB FACING UPWARDS OR DOWNWARDS SIMPLY BY CHANGING YOUR FRONT AND BACK GAUGE PORTS. THERE ARE (2)  1/8" FEMALE GAUGE PORTS ON OPPOSITE SIDES OF EACH OTHER. ONE PORT COMES WITH A AN 1/8" NPT PLUG.
