110v 4500psi 1.5kw 2hp Air Compressor

Items Description SCU100 Portable electric driven series Charging Rate: 85-100L/min; 3.0-3.5cfm Suction pressure: atmosphere Working pressure: 20-30MPa， 200-300bar, 3000-4500psi Media: air No.of stage and cylinder: 4 Electric motor: 2.2kw 220-230v 50/60hz（type A）;1.8kw/ 110v 60hz（type B） Cooling: air cooled Driven: belt driven Shout down：manual stop Pressure indicate：Gauge Protection ：Safety & relief valve in last stage Filtration：water separator and oil filter Lubricant: ISO grade 100/150 SAE 40/50 synthetic compressor oil (food grade) Dimension：700 X 400 X 400mm Weight：45kg Noise：Less than 65 dB(A) Package list Valve plate gasket Primary piston ring Secondary intake valve plate Primary intake valve Primary exhaust spring Cushion Quick connect hose + handwheel Notice 1. The bottle filling of the air compressor must be greater than the pressure of the gas cylinder to fill the bottle! 【Air Compressor Pressure>Cylinder Pressure】 2. Suggestion for bottle filling: 3L-12 L / 3L≤ 12 L 3. Use of gas cylinder: Fire fighting, diving breathing 4. Recommended operating time of the machine (machine operating load range): The temperature cannot exceed 85°C 5. Estimated filling time: Recommendations for filling 12L gas cylinders: 1) The cylinder pressure is 200bar, and the estimated time is 24 minutes 2) The cylinder pressure is 300bar, and the estimated time is 36 minutes Note2 This series are high pressure air compressor. It compresses atmosphere air go to pressure 20/30Mpa, 3000/4500psi, after be purified and separated by the filter and separator. It discharge clean air accords to GB18435-2001 breathing air standard. It is widely be used for breathing of diving and fire fighting; paintball PCP shooting and other high pressure filed industries by its reliability, durability and portability. ￭ Check the electric voltage in nameplate is same as your local electric supply ￭ Check the lubricate oil has been put in before running ￭ Increase rated pressure setting is forbidden ￭ There is potential danger of pipe burst or connect fitting blow off under high pressure, please avoid body too near compressor when it running ￭ if there are no auto stop function, don't leave compressor until it reach rated pressure and shut down it by manual

Returns Accepted for this item if it's within 30 Days
